Place of Origin: | China |
Brand Name: | Kimpok |
Certification: | EC/FCC/ROHS |
Model Number: | KP-HDT25W |
Minimum Order Quantity: | 1piece |
---|---|
Price: | Negotiation |
Packaging Details: | export packing standard |
Delivery Time: | 5 working days after received the payment |
Payment Terms: | L/C, T/T, PayPal |
Supply Ability: | 1000pcs per month |
Frequency:: | 300-900MHz,1.2G/2.4G/5.8GHz | RF Power:: | 15-25 Watt (adjustable) |
---|---|---|---|
Video Resolution: | 1920*1080 | Power Supply: | DC11-14.5V/1.9A |
Size: | 220*275*78mm | Weight: | 5.1kg |
Highlight: | 4CH Digital Video Recorder |
HD Wireless AV Sender Long Range 25W COFDM Video Transmitter for Marines and UAV
Wireless HD Transmitter Introduction:
It’s a new powerful HD COFDM video audio transmitter, can up to 15-25W power which support transmitting over a long distance.Using the core technology 4th generation mobile communication COFDM modulation and low delay full-HD 1080P technique that can transmit high quality and stable image under the condition of fast moving or many buildings as obstacles(NLOS). Suitable for vehicles - cars, boat - boats, cars - a building, ship – a base station, aircraft –a buiding/vehicle and etc. high-definition moving video signal transmission, the carrier velocity greater than 450 km / h.Widely used in public security, armed police, fire, field armies,other military departments and broadcasting, urban management, civil defense, transportation, customs, oil, mining, water, electricity, geology, finance and other relevant state departments.
Features:
Specification:
Frequency | 300-900MHz,1.2G/2.4G/5.8GHz |
RF power | 15-25Watt(adjustable) |
Power supply | DC11-14.5V/1.9A |
Modulation | COFDM 2K QPSK |
RF Bandwidth | 4/8MHz(adjustable) |
Delay time | Only has 150ms |
FEC | 1/2 2/3 3/4 7/8 |
Guard Interval | 1/32 1/16 1/8 1/4 |
Data Encryption | AES 128/256 Bits |
Max speed | 450km/h |
Video Input | BNC: D1 standard definition |
HD: HD1080I/1080P, 720P, 576, 480 | |
SDI:HD1080I/1080P, 720P, 576, 480 | |
Video compression format | H.264 |
Video Resolution | 1080p/1080i@60fps, 1920*1080 definition |
RF Interface | N |
Work environment | -40℃~70℃ |
Video Format | PAL/NTSC(self-adaption) |
Transmission Distance |
15km NLOS distance(ground to ground) 20km-35km LOS distance(on sea) |
Case Material Aluminum | (black) |
Size | 220*275*78mm |
Weight | 5.1kg |
Remote HD Wireless Video Transmitter Package:
Application:
Kimpok is specialized in COFDM, TDD and Analog wireless video transmission products for over 10 years, including Wireless Video Transmitter, HD Video Wireless Transmitter and Receiver, quality UAV/UGV Wireless Video Transmitter, and CCTV Wireless Sender, products are applied widely among Public Security Bureaus, Forest Fire Prevention Departments, Maritime Bureaus, Oil Field, Construction Sites, Tunnels, UAV, UGV, Automobiles and so on.
