Place of Origin: | CHINA |
Brand Name: | BOSCOM |
Model Number: | BS-5608MD |
Price: | Negotiable |
---|---|
Payment Terms: | T/T, Western union, Paypal |
High Light: | hdmi digital video recorder,dvr hdmi output |
---|
Adopts electric circuit protection design which effectively avoid breakdown by static electricity and lightning. The unique triple Watchdog Timer function ensures the stability of the DVR.
Specifications:
Model Number |
BS-5608MD |
|
Operating System |
LINUX operating system |
|
Image Code Control |
H.264 |
|
Dual Stream |
Every channel can set |
|
Video Standard |
PAL/NTSC |
|
Monitoring Image Quality |
D1(704*576) |
|
Image Dynamic Detection |
Each screen can detect 396(22*18)detection areas and set 6-level sensitivity |
|
Playback Image Quality |
PAL |
2ch D1(704*576) + 6ch CIF (320*288) 200 fps |
|
NTSC |
2ch D1(720*480) + 6ch CIF (320*288) 240 fps |
Region Cover |
Every channel can set 4 cover regions |
|
Record Mode |
Support manual, auto, dynamic detection, alarm trigger |
|
Recording Playback |
Support 1ch to 8ch playback simultaneously |
|
Video Bit Rate |
48Kbps-2048Kbps, support user-defined, MAX 2048Kbps |
|
Bit Stream Type |
Composite stream/video stream |
|
Audio Compression Standard |
G.711A |
|
Audio Bit Rate |
64kbps |
|
Backup Way |
Support HDD, U disk, SD card, USB mobile HDD, USB burner, network storage and backup |
|
Operation Way |
Mouse, remote control, front panel button, keyboard controller |
|
Local Login |
User name and password |
|
Recording Storage |
Local HDD, SD card, network |
|
External Ports |
Video Input |
8ch BNC |
|
Audio Input |
4ch RCA |
|
Voice Talkback Input |
1 RCA port, the same channel as the first channel of the audio input |
|
Video Output |
2ch BNC, 1ch VGA (Resolution: 800*600, 1024*768,1280*1024 optional), 1ch HDMI(optional) |
|
Audio Output |
1ch RCA |
|
Network Port |
1 RJ45, 10M/100M self-adaptive LAN port |
|
RS485 Port |
Full duplex standard 485 port, support 19 kinds PTZ protocol |
|
USB Port |
2 USB 2.0 ports (one is on the front panel, the other one is on the rear panel) |
|
Alarm Input |
8ch |
|
Alarm Output |
1ch |
|
HDMI Port |
1 standard HDMI port (optional) |
|
SD Card Port |
1 SD card port |
|
Wireless Port |
3G, WIFI |
HDD |
HDD Port |
2 SATA HDD ports |
|
Max Capacity |
Every port MAX supports 2TB HDD |
Mobile Surveillance |
Support( iPhone, Windows Mobile, BlackBerry, Symbian, Android) 3G mobile phones |
|
Power Supply |
12V2.6A |
Consumption |
≤20W (without HDD) |
Operation Temperature |
-10℃-+55℃ |
Operation Humidity |
10%-90% |
Dimension |
Equipment: 315mm*225mm*52 mm, Packing: 409mm*365mm*129mm |
Weight(without HDD) |
N.W.1.45Kg, with packing 2.76Kg |
Carton |
Size: 675mm*425mm*385mm; Weight: 14.88 Kg; 5 pcs in a carton. |
Installation Way |
Desktop installation |
